Publish Coverage Tab

You can publish new coverages using the Publish Coverage tab. Note that to use the publish coverage page you need to be an authenticated user with administrator role.

This page shows an HTML table with all GeoRaster objects. You can choose to publish or unpublish individual GeoRaster objects by right-clicking the desired row.

A GeoRaster cannot be published more than once in a WCS instance.

Test Tab

You can send post requests using the Test tab. This tab is initially empty, in which case you need to send a GetCapabilities request to populate following elements:

• Operation: An HTML select element with all operations discovered on last GetCapabilities response.
• Coverage: An HTML select element which is populated with content of last GetCapabilities response. It contains all Coverage IDs from GetCapabilities response received.

Create Request: Populates the request test area with a request to the specified operations, coverage IDs, and operation URLs.

Request: A text area whose content will be sent in a post request to the Operation URL. This element can be populated by clicking Create Request, and you can edit that request as needed.

Operation URL: The URL where the request is to be sent. This element can be populated by clicking Create Request, and you can edit that request as needed.

Send Request: Sends an HTTP post request to the Operation URL using the content of the request. The response of the HTTP post request will be shown in the Response.

Response: A text area populated with the response of a Send Request operation.

Log Tab

You can visualize and download WCS log files using the Log tab. Log files are generated inside the directory referenced by the SDOWS_HOME environment variable. Using this tab requires administrator credentials.

All Oracle WCS log files have file names in the form wcs_<data_source_name>_n.log, where n is a consecutive number, and for the newest log files n is 0 (zero).

This tab shows the content of the wcs_<data_source_name>_0.log file, which has the most recent log messages generated by the WCS server. However, you can select other log files to see their contents. You can also refresh the display to include new log messages generated since the page was loaded or last refreshed.

Download lets you download the selected log file in zip format.

Service Configuration Tab

As an administrator, you can configure WCS logging, GDAL parameters, and GetCapabilities responses (ServiceIdentification and ServiceProvider) by modifying the WCSConfig.xml file using the Service Configuration tab.

You can configure logging attributes such as:

• Log level: The logging levels can be SEVERE, WARNING, INFO (default), CONFIG, FINE, FINER, FINEST, or ALL.
• Log file size: Log rotation is supported based on the file size. By limiting the number of files, you can limit how much disk space the log files will take. Log files are generated inside the directory referenced by the SDOWS_HOME environment variable, and they have names in the form wcs_<data_source_name>_n.log, where wcs_<data_source_name>_0.log has the most recent log messages; and when it has reached its file size limit, the oldest file is removed and all log files are renamed so that wcs_<data_source_name>_0.log can be used for the next set of log messages.
• Log size limit: This is the file size limit in megabytes (default 10).
• Log file count: This denotes the maximum number of log files.

The GDAL database connection is configured using the gdalParameters element as follows:

• <gdalParameters user="<user>" password="!<password>" connectionString="<db_host:port:sid>" temporaryDirectory="<directory>" />
• The specified user must have privileges to read all GeoRaster objects that are published as coverages. It is recommended that this user be the same as the WCS user.
• The password must be encrypted by the server. You must add an exclamation point (!) character at the beginning of password attribute, to make the server encrypt the password.
• The temporary directory should point to a writable directory to be used by GDAL to generate output files. Example: /tmp

To validate that GDAL was properly configured, go to the About tab in the Oracle Spatial Web Services administration console (http://<host>:<port>/oraclespatial), which shows the GDAL version if it was properly configured.

ServiceIdentification and ServiceProvider can be configured by uncommenting the appropriate element and specifying the desired information, complying with the XML schemas at http://schemas.opengis.net/ows/2.0/owsGetCapabilities.xsd.

When you click Save Changes, the server applies the changes, and no restart is needed.
